IMET SIRIO 315 SH circular saw

Circular saws

IMET SIRIO 315 SH circular saw

31 644,80 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

The IMET SIRIO 315 SH disc cutter is a semi-automatic disc cutter with a column feed for cutting from 0° to 45° to the right and from 0° to 60° to the left. An ideal machine for cutting bars and profiles (also with high durability).

Quantity

IMET SIRIO 315 SH is a circular saw with vertical descent semiautomatic. SIRIO is suitable to cut up to 45° right and 60° left and can be used in professional workshops for production of steel profiles, tubes and pipes (even with high resistance materials).

All SIRIO circular saws have a rigid, solid vertical dovetail structure with that provides high stability during the cutting process, reducing vibrations and binding, helping saving blade file.

Clamping vice on adjustable guides, sliding on the working plate with rapid locking system managed by handwheel.

Perfect positioning and high cutting accuracy provided by adjustable easy stops system at 0° and 45° with graded scale and adjustable lenght stop.

40mm blade spindle that allows to mount both 315mm (standard) and 300mm blade (using a smaller blade, cutting capacity on the rounds is 100mm).

The semiautomatic version SIRIO 315 SH has electro-pneumatic functioing with hydraulic control of the head descend speed and pneumatic vice; easy regulation of the first and end-cut position with sliding limit switch.

DEVICE FEATURES:

The machine is designed for cutting carbon steel, alloy steel, cast iron, etc.
Manual vice
Manual feed
Possibility of cutting at an angle of up to 45 degrees to the left and 60 degrees to the right

Optional equipment (additionally paid):

Minimal lubrication system - The lubrication system cancels the dispersion of the coolant without damaging or affecting the life of the blade. The system is equipped with a 1.3l tank and nozzle.
Pneumatic vice (opening/closing synchronysed with the head motion).
Vertical vice (to be used coupled with pneumatic vice).
Two pairs of cast iron V jaws to fittings bundles and round bars (max diameter 85 mm.) with tools to mount them.
SIRIO 315 can mount blade of 40mm hole
Adapter to synchronize the RTD/RTP table and the head motion

Technical data	Unit	Value
The diameter of the cutting disc	[mm]	315
Vise opening width	[mm]	150
Disc bore diameter	[mm]	40
Cutting disc speed	[rpm/min]	17/33
Cutting disc motor power	[kW]	1.5/1.8
Working height	[mm]	920
Dimensions	[mm]	800x900x1950
Weight	[kg]	360
